MRI Tenography Shows No Clear Advantage for Equine Manica Flexoria Tears
Animals 2025
Does Low-Field MRI Tenography Improve the Detection of Naturally Occurring Manica Flexoria Tears in Horses?
Anton D. Aßmann, José Suàrez Sànchez-Andrade, David Argüelles, Andrea S. Bischofberger
Background
Manica flexoria (MF) tears, a common pathology within the digital flexor tendon sheath (DFTS) in horses, are challenging to diagnose accurately using standard imaging methods like ultrasonography and radiography. High-field MRI provides detailed imaging but is less accessible. Low-field standing MRI, while more available, suffers from reduced spatial resolution. Gadolinium-enhanced MRI tenography (MRIt), used successfully in human and veterinary imaging, has been proposed to enhance diagnostic performance for MF tears.
Methods
This retrospective cross-sectional study involved ten horses with DFTS-related lameness confirmed by diagnostic blocks. All underwent ultrasonography, contrast radiography, low-field MRI, MRIt, and tenoscopy. Two blinded radiologists evaluated images for the presence and laterality of MF lesions. Tenoscopy served as the reference standard. Sensitivity and specificity were calculated for each modality, and statistical comparisons were made using McNemar’s test.
Results
Of the ten horses, seven had confirmed MF lesions via tenoscopy. MRIt and contrast radiography each detected 5 of 7 lesions (71% sensitivity, 100% specificity), while MRI and ultrasonography each detected 4 of 7 (57% sensitivity). MRI maintained 100% specificity, whereas ultrasonography showed only 33%. Differences in sensitivity and specificity between modalities were not statistically significant (p = 1). MRIt offered the unique benefit of lesion laterality determination.
Limitations
The primary limitation was the small sample size, which limited statistical power. Additional technical constraints included the use of short MRI protocols with thick slice acquisition (5 mm) and motion artifacts inherent to low-field MRI in standing horses. The results may not generalize to chronic or complex cases or to higher-resolution MRI systems.
Conclusions
Low-field MRIt did not significantly enhance the detection of naturally occurring MF tears compared to standard low-field MRI or contrast radiography. While MRIt and MRI provided improved specificity over ultrasonography, they did not outperform contrast tenography overall. MRIt may be beneficial in preoperative planning due to its ability to determine lesion laterality, but its routine clinical use requires further investigation with larger sample sizes.

Lateromedial contrast radiograph demonstrating two diagnostic criteria used for assessment of manica flexoria lesions. The two parallel lines which delineate the manica flexoria just above the proximal sesamoid bones, at the dorsal border of the deep digital flexor tendon, are not visible (arrow), and there is an isolated area of contrast overlying the dorsal border of the deep digital flexor tendon at the level of the manica flexoria (arrowhead).
